Performance
Engine Power at 2,250 rpm> 60 (B.S) hp
Torque at 1,600 rpm 212 Nm
PTO Power at Rated 48hp
Engine Speed
*Certified at BS AU 141a 1971 **Manufacturer’s Estimate
Electrics
Voltage 12V, Negative Earth
Battery 110 Ah
Starter 2.2 kW
Alternator 32 Amp
Transmission
Type Sliding Spur
Number of Gears 8 Forward, 2 Reverse
Road Speed at 2,250 Engine RPM with 14.9/13-28 rear tyres
Gear Speed (km/hr)
Forward 1 (First Low) 2.7
Forward 2 3.9
Forward 3 5.3
Forward 4 7.2
Forward 5 (First High) 10.6
Forward 6 15.6
Forward 7 21.3
Forward 8 28.7
Reverse 1 (Low) 3.6
Reverse 2 (High) 14.5
Hydraulics
Functions Draft Control, Position Control Response Control, Constant Pumping
Pump Type Reciprocating, Ferguson Pump
Oil Flow 16 ltr/mix
Pressure 21.0 Mpa at normal operating temperature
Links Horizontal
Lower Links With Cat, I & II Interchangeable Balls
Rear Axle & Brakes
Brake Type Oil immersed, Multi-disc
Brake Actuation Mechanical
Axle Type Straddle with apicyclic redution
Parking Brake Hand Lever Operated
Tyres
Front 7.50 – 16 (6PR)
Rear 14.9 / 13 – 28 (6PR)
Clutch
Type Dual
Diameter 305 x 254 mm
Front Axle
Type Box Section, Adjustable
Steering
Type Manual
Track Adjustment
Front Axle 1,245 – 1,854 mm
Rear Axle 1,423 – 2,134 mm
Engine
Make / Type Diesel T 3.1524
No. of Cylinders 3
Rear Axle 1,423 – 2,134 mm
Make / Type Diesel T 3.1524
No. of Cylinders 3
Injection Direct
Bore 91.4mm
Stroke 127.0mm
Capacity (litres) 2.5 L
Compression Ratio 15.5:1
Aspiration Turbo
Starting Aid Thermostart
Throttle Control Hand and Feet
Cooling Water
Air Cleaner Type Oil Bath
Air Pre-Cleaner Over Bonnet, Air Swirl
Fuel Filter Dual, High Capacity
Exhaust Vertical
Oil Cooler Air Cooler, Fin Type
Power Take Off
Type Live
Engine Speed at 540 pto rpm 1,789 rpm
Shaft Diameter 35mm
No. of Splines 6
Instrumentation
Guages Technometer, Hourmeter, Fuel Level, Battery Condition & Water Temperature
Warning Lights Direction Indicators, Battery Charge, Headlight Main Beam, Low Engine Oil Pressure & Brake Lights
Weight & Dimensions
Weight
Gross Weight 1,900 kg
Dimensions
Wheel Base 1,892 mm
Overall Length 3,260 mm
Overall Width (Min) 1,890 mm
Height
Over Exhaust 2,220 mm
Over Steering Wheel 1,490 mm
Turning Circle
With Brakes 5,840 mm
Without Brakes 6,580 mm
Ground Clearance
Under Gear Box 400 mm
Capacities
Fuel Tank 47.0L
Engine Pump 6.8L
Cooling System 10.2L
Hydraulic System 36.0L
Steering Box 0.9L
Oil Bath Air-Cleaner 0.5L
Standard Equipment
Weight frame without weights, standard tool box with set of tools, Top Link, Top Link End Cat-I, Cat I & II balls, Check Chains, Spring Suspension Seat, Flat Top Fender & Operator’s Manual
Optional Equipment
Front End Weights, Swinging Draw Bar, Sun Canopy, Pintle Hook
