Performance
Engine Power at 2,000 rpm> 75 (B.S) hp
Torque at 1,400 rpm 290 Nm
PTO Power at Rated 69.5 hp
Engine Speed
PTO Power at 540 rpm 63.0 hp
*Certified at BS AU 141a
Electrics
Voltage 12V, Negative Earth
Battery 110 Ah
Starter 2.8 kW
Alternator 45 Amp
Transmission
Type Sliding Spur
Number of Gears 8 Forward, 2 Reverse
Road Speed at 2,250 Engine RPM with 16.9/14×30 rear tyres
Gear Speed (km/hr)
Forward 1 (First Low) 2.3
Forward 2 3.4
Forward 3 4.7
Forward 4 6.3
Forward 5 (First High) 9.3
Forward 6 13.6
Forward 7 18.6
Forward 8 25.0
Reverse 1 (Low) 3.2
Reverse 2 (High) 12.7
Hydraulics
Functions Draft Control, Position Control Response Control, Constant Pumping
Pump Type Reciprocating, Ferguson Pump
Oil Flow 16.7 ltr/min
Pressure 21.2 Mpa at normal operating temperature
Lift Capacity with Lower 2,145 kg With Cat, I & II Interchangeable Balls
Links Horizontal
Rear Axle & Brakes
Axle Type Straddle with apicyclic redution unit
Brake Type Oil immersed, Multi-disc
Brake Pedal Pendant
Braking Area 1.774 sq. cm
Brake Actuation Hydraulic
Parking Brake Hand Lever Operated
Tyres
Front 7.50 – 16 (6PR)
Rear 16.9 / 14 – 30 (6PR)
Clutch
Type Dual
Diameter 305 x 254 mm
Lining Material Cerametallic
Front Axle
Type Heavy Duty Box Section, Adjustable
Steering
Type Hydrostatic
Track Adjustment
Front Axle 1,271 – 1,881 mm
Rear Axle 1,423 – 2,134 mm
Engine
Make / Type Diesel / 4.248
No. of Cylinders 4
Injection Direct
Bore 101 mm
Stroke 127 mm
Capacity (litres) 4.07 L
Compression Ratio 16:1
Compression Ratio 16.5:1
Aspiration Natural
Starting Aid Thermostart
Throttle Control Hand and Feet
Cooling Water
Air Cleaner Type Oil Bath
Air Pre-Cleaner Oil Bath
Fuel Filter Dual, High Capacity
Exhaust Vertical Muffler under Bonnet
Note: This is a premium heavy duty engine with tuffrided cranckshaft for longer life in adverse conditions.
Power Take Off
Type Live
Engine Speed at 540 pto rpm 1,789 rpm
Shaft Diameter 35mm
No. of Splines 6
Instrumentation
Guages Technometer, Hourmeter, Fuel Level, Battery Condition & Water Temperature
Warning Lights Direction Indicators, Electric Charge, Headlight Main Beam, Low Engine Oil Pressure, Brake Lights & Auxiliary Socket
Weight & Dimensions
Weight
Gross Weight 2,355 kg
Dimensions
Wheel Base 2,170 mm
Overall Length 3,670 mm
Overall Width (Min) 1,970 mm
Height
Over Exhaust 2,485 mm
Over Steering Wheel 1,730 mm
Turning Circle
With Brakes 7,260 mm
Without Brakes 8,095 mm
Ground Clearance
Under Gear Box 465 mm
Capacities
Fuel Tank 108.0L
Engine Pump 7.5L
Cooling System 15.2L
Hydraulic System 36.0L
Hydrostatic Steering Reservior 2.0L
Oil Bath Air-Cleaner 0.7L
Brake Oil 0.25L
Standard Equipment
Weight frame without weights, standard tool box with set of tools, Top Link, Top Link End Cat-I, Cat I & II balls, Check Chains, Spring Suspension Seat, Flat Top Fender & Operator’s Manual
Optional Equipment
Front End Weights, Swinging Draw Bar, Sun Canopy, Pintle Hook
